Imaging hyperspectral camera
FS2X series
FigSpec® series of imaging hyperspectral cameras adopt transmission grating splitter module with high diffraction efficiency and high sensitivity surface array camera, combined with built-in scanning imaging and auxiliary camera technology, which solves the difficult problems of traditional hyperspectral cameras, such as external push scan imaging mechanism and complex focus. It can be directly integrated with standard C interface imaging lens or microscope to achieve rapid spectral image acquisition.
Product features
Visible spectrum/NIR： · Spectral range: 400-1000nm, wavelength resolution better than 2.5nm, up to 1200 spectral channels. · Image resolution up to 1920*1920 SW-NIR： · Spectral range: 900-1700nm, wavelength resolution better than 6nm, up to 512 spectral channels · Image resolution up to 640*640
Technical parameters

Model

FS-20

FS-22

FS-23

FS-24
FS-25

FS-27

Spectroscopic

mode

Grating

Grating

Grating

Grating

Grating

Grating

Image resolution

480*480

1920*1920

1920*1920

1280*1280640*640

1280*1280

Dynamic range

12 bits

12 bits

12 bits

12 bits14 bits

12 bits

Imaging speed

≤15 seconds

≤15 seconds

≤5 seconds

≤10 seconds≤5 seconds≤10 seconds

Number of

spectral channels

150

600

1200

680512

1024

Spectral range

400-700nm

400-1000nm

400-1000nm

400-1700nm900-1700nm

900-1700nm

Spectral FWHM

2.5nm

5nm

2.5nm

13nm6nm

6nm

Slit width

25um

25um

25um

25um25um

25um

Transmission

efficiency

60%

60%

60%

60%60%

＞60%

Stray light level

0.5%

0.5%

0.5%

0.5%0.5%

＜0.5%

Pixel size

5.86um*5.86um

5.86um*5.86um

5.86um*5.86um

5um*5um15um*15um

5um*5um

Detector type

CMOS

CMOS

CMOS

InGaAsInGaAs

InGaAs

Dimensions of

sensor imaging

surface

11.3*7.1mm

11.3*7.1mm

11.3*7.1mm

/9.6mm x 7.68mm

9.6mm x 7.68mm

Standard lens

focal length

25mm

25mm

25mm

16mm25mm

25mm

Minimum working

distance

100mm-∞

100mm-∞

100mm-∞

100mm-∞100mm-∞

150mm-∞

Field angle

25°

25°

25°

22.6°17°

14.5°

Minimum exposure

time

34us

34us

21us

/50us

1us

Maximum exposure

time

10s

10s

10s

/1s

10s

Signal-to-noise

ratio

600/1

600/1

600/1

600/1600/1

600/1

Data interface

USB3.0

USB3.0

USB3.0

USB3.0USB3.0

USB3.0

Camera lens

interface

C-Mount

C-Mount

C-Mount

C-MountC-Mount

C-Mount

Parts

USB3.0

Transmission line

USB3.0

Transmission line

USB3.0

Transmission line

Lens, USB3.0 data

cable, power adapter

USB3.0

Transmission line

USB3.0

Transmission line

Imaging function

With ROI function

Single area ROI

can be achieved

With ROI function

Single area ROI

can be achieved

With ROI function

Single area ROI

can be achieved

ROI function, can

realize multiple area ROI

With ROI function

Single area ROI

can be achieved

ROI function, can

realize multiple area ROI

Auxiliary imaging

function

Auxiliary viewfinder

Monitoring the

shooting area

Auxiliary viewfinder

Monitoring the

shooting area

Auxiliary viewfinder

Monitoring the

shooting area

Auxiliary viewfinder

Monitoring the

shooting area

Auxiliary viewfinder

Monitoring the

shooting area

Auxiliary viewfinder

Monitoring the

shooting area

Power supply

mode

Built-in battery

Built-in battery

Built in battery

Built in batteryBuilt in battery

Built in battery

Host size*

25.5cm*13.8cm*10.7cm

25.5cm*13.8cm*10.7cm

25.5cm*13.8cm*10.7cm

/

33.5cm*18.2cm*14.3cm

24.8cm*14.5cm*14.5cm

Weight**
Less than 2.8kgLess than 2.8kgLess than 2.8kg/Less than 5.3kg
2535g

Power dissipation

50W

50W

50W

/50W

50W


* size without lens and handle

** weight without lens


Application cases
